Project |
Parameter |
Project |
Parameter |
||
|
Voltage |
(V/Hz)380/50 |
Work efficiency |
1 block / (38 seconds) |
||
|
Aluminum frame height |
3300-50(mm) |
Work table height |
(mm)900±50 |
||
|
Maximum group frame dimensions |
2000X1100X（30-50）mm |
Group box precision |
The difference in edge size is ± 0.5mm Diagonal size difference ± 1.0mm |
||
|
Minimum group frame dimensions |
1300X800X（30-50）mm |
||||
|
Working pressure |
0.6Mpa~0.8Mpa |
||||
|
Installed total power |
（kw）7 |
Whole line weight |
（kg）3400 |
||
